XL6009 DC-DC Adjustable Step-Up Boost Power Converter Module

XL6009 DC-DC Step-Up Power Supply with SMD LED

The XL6009 DC-DC Boost Converter is a highly efficient, step-up switching regulator designed to deliver stable power in applications requiring higher output voltages. Built around the advanced XL6009E1 IC and second-generation high-frequency switching technology, this module outperforms older solutions like the LM2577 in both efficiency and cost-effectiveness. It features an adjustable output voltage range from 5V to 35V, making it ideal for boosting battery or low-voltage sources to power microcontrollers, displays, and other electronics.

With a maximum input current of 4A and integrated 4A high-efficiency MOSFET switches, the XL6009 achieves conversion efficiencies of up to 94%. Its high switching frequency of 400kHz allows for smaller external filter components and reduced output ripple, resulting in cleaner, more stable power delivery.

This compact module includes clearly labeled terminals for easy connection and offers excellent load and line regulation. Designed for simplicity and reliability, it requires minimal external components and is well-suited for both DIY projects and industrial applications.

Features:

• Wide Input Voltage Range: Supports 3V to 32V input voltage.
• Adjustable Output Voltage: Provides an output range of 5V to 35V.
• High Current Capability: Handles up to 4A input current with robust power handling.
• High Efficiency: Conversion efficiency up to 94%, thanks to integrated 4A MOSFET switches.
• High Switching Frequency: Operates at 400kHz, enabling smaller filter components and lower ripple.
• Low Output Ripple: Typical ripple voltage of only 50mV for cleaner power output.
• Compact Design: Small form factor with labeled terminal pins for ease of use.
• Non-Isolated Topology: Non-synchronous boost converter design optimized for cost and performance.
• Improved Performance: Offers superior efficiency and thermal performance compared to LM2577-based modules.

Applications:

• Battery-powered systems requiring voltage boosting (e.g., Li-ion, NiMH).
• Power supply for displays, motors, and sensors from low-voltage sources.
• Renewable energy systems such as solar panels.
• DIY electronics and Arduino/Raspberry Pi projects needing higher voltages.
• Portable devices and mobile power solutions.

The XL6009 DC-DC Step-Up Module delivers a reliable, efficient, and compact solution for increasing DC voltage levels, combining modern switching technology with user-friendly design for versatile power management needs.
